Multistage FE Hydraulic Telescopic Cylinder for Dump Truck

Multistage Fe Hydraulic Telescopic Cylinder for Dump Truck

production details:
Model  Rated Press(Mpa) Lift capacity(T) Weight(KG) Oil PortOil Volume(L)
FE 3TG-F091*3205-1424  20 11-18 921"SAE16
FE 3TG-F110*3205-1399  20 21-46 981"SAE24
FE 3TG-F110*3700-1529  20 20-37 1091"SAE28
FE 3TG-F129*3460-1449  20 33-59 1291"SAE37
FE 3TG-F129*3880-1609  20 33-59 1421"SAE42
FE 3TG-F149*3880-1644  20 47-68 1681"SAE56
FE 4TG-F149*4620-1484  20 35-70 1711"SAE59
FE 4TG-F149*4940-1529  20 34-66 1791"SAE63
FE 4TG-F169*4620-1479  20 51-83 2061"SAE78
FE 4TG-F169*5180-1604  20 50-83 2271"SAE88
FE 5TG-F169*5355-1394  20 35-66 2121"SAE80
FE 5TG-F169*5780-1559  20 34-60 2241"SAE87
FE 5TG-F169*6180-1559  20 34-58 2361"SAE93
FE 5TG-F169*6480-1604  20 34-56 2471"SAE97
FE 5TG-F191*6180-1527  20 49-84 2811"SAE122
FE 5TG-F214*7130-1722  20 60-84 3801"SAE188
Cylinder Tube O.D.131mm-242mm
Operating Pressure16Mpa-20Mpa
Numbers of Stage3, 4, 5, 6
Largest Moving Stage Diameter 110mm-214mm
Stroke 2900mm-9030mm
Closed Length 1320mm-2177mm
Extended Length 4220mm-11207mm
Plunger Mount Thickness 42mm-52mm
Warranty Period 14 months after date of production
Piston rod head radius53-62mm
Oil PortG1/1''SAE
Cardinal Axi60mm-65mm
Port Size50mm-60mm

 Product Advantages
1 more than 22 years manufacture experience
2 Our own factory
3 ISO9001-2008
4 Competitive price and high quality
4 Competitive price and high quality
5 Based on your drawing or requirement
6 rigid matching control and proper seals
7 Easy install and easy maintain

Product Process:

Multistage Fe Hydraulic Telescopic Cylinder for Dump Truck

1.Raw materials entering the factory, 27SiMn, 40CrMo, ST52, 45# steel tubes or bars for choice
2.Do the pre-treatment including pickling, phosphating and saponification, and then cold-draw the seamless steel tubes.
3.Put the steel tubes into the tempering furnace to do the stress relief annealing in convenience of the subsequent the processing.
4.Multi-roll straightening machine, with 10 straightening points, achieves the automatic rolling straight improving the efficiency greatly
5.Heat treatment to obtain work pieces with different properties by changing their internal microstructure or surface chemical composition.
6.Cylindrical degree can be controlled within 0.03mm and the surface roughness is up to 0.4 by honing with range:φ40mm-φ450mm and longest length: 12000mm
7.Machining processes to obtain high precision parts with complex shapes strictly according to the detailed drawings.
8.Electroplating production process fulfills the functional and ornamental requirements for coating work pieces of different dimensions according to specific application requirements.
9.Cleaning all the parts by automatic cleaning machine in the special solution and under special  temperature control effectively.
10.All the parts are assembled into complete cylinders according to the strict assembly instructions by skillful workers in dust-free workshop.
11.Do proof pressure and performance tests to check whether the cylinders can operate smoothly and stably under the specified pressure with no leakage and deformation.
12.Do the painting including high quality primer and topcoat to obtain beautiful appearance and protect  the cylinders against the anticorrosion.
13.Wooden pallet or boxes packing with plastic films wrapped on the surface, suitable for long-time sea  transport.

Quality Control:
>All specification is designed by professional engineer.
>All material is high quality-Seal kits were purchased from USA, Japan, UK and Sweden.
>All material is processed by skilled workers and advanced CNC lathe
>All cylinders are 100% tested before package to ensure every cylinder is qualified for its purpose
>Package is air cushion film for each cylinder and steel case for all cylinders to ensure goods can arrive at customer safely
>14 months warranty and long time track service is offered to solve any problems you meet after sale.

After-sales service

Warranty period:

Wantong Hydraulic warrants all cylinders to be free from any defects in material or workmanship under normal use and service for a period of 14 months

 Hydraulic cylinder problems occur at warranty period:

(1) New cylinder replace;
(2) price discount in the next order;
(3) the "repair fee" pay: repair fee required to within a reasonable range: the cost of wantong repair problem hydraulic cylinder < repair fee < the cost of production of a new hydraulic cylinder;
(4) for strategic customers, one to one special treatment.

Our company:

Our Slogan:

"Pursue zero defect of our products, and realize zero customers' complains"
Company introduction:

Multistage Fe Hydraulic Telescopic Cylinder for Dump Truck

    Founded in 1995, with registration capital of 60 million RMB, Shandong Wantong Hydraulic Co., Ltd is specialized in hydraulic products design,R&D and manufacturing.

We mainly produce Hydraulic Cylinder including Vehicle Hydraulic Cylinder, Coal Mining Hydraulic Cylinder, Engineering Hydraulic Cylinder ,Oil field cylinder and Ocean Engineering Hydraulic Cylinder.Also we can design and manufacture various special purpose hydraulic cylinders such as agriculture hydraulic cylinder,industry hydraulic cylinder, 6 DOF platform, machine tools, etc.

 Our company covers an area of 180 thousand square meters (193 thousand square feet),and has more than 500 employees.We have solid and advanced production equipments including cold drawing line, heat treatment line, surface treatment line, testing machines and various CNC machines, totally 700 sets of machines.

 All production steps are finished in same factory which guarantees good quality and short lead time. All the products have passed validation of ISO/TS16949, CCRI, CCS, and DNV AND ABS,API,etc.

Company advantage:
>Professional manufacturer& supplier of Hydraulic Cylinders for more than 22 years;
>Hydraulic Cylinders Certification ISO9001:2008, SGS, TS16949, RoHS, CNAS Certification;
>Experience in export North America, Australia, Asia, Middle East, Africa;
>Hydraulic Cylinders can be Make according to client's requirements;
>The Hydraulic Cylinders can be used for Dump Truck, Tipper Truck, Trailer, Agricultural Machinery, Engineering Machinery, Garbage Truck, Landing Platform etc;
>We are the supplier of Sinotruk, CNHTC, CIMC, Wuzheng, Beiben Truck, Baic Group, FOTON, HOWO, JAC, Sichuan Hyundai, Dayun, Shanxi Automobile, most of famous truck manufacturing and refitting company use our telescopic cylinder as first choice
