|Model||Rated Press(Mpa)||Lift capacity(T)||Weight(KG)||Oil Port||Oil Volume(L)|
|Cylinder Tube O.D.||131mm-242mm|
|Numbers of Stage||3, 4, 5, 6|
|Largest Moving Stage Diameter||110mm-214mm|
|Plunger Mount Thickness||42mm-52mm|
|Warranty Period||14 months after date of production|
|Piston rod head radius||53-62mm|
1 more than 22 years manufacture experience
2 Our own factory
4 Competitive price and high quality
4 Competitive price and high quality
5 Based on your drawing or requirement
6 rigid matching control and proper seals
7 Easy install and easy maintain
1.Raw materials entering the factory, 27SiMn, 40CrMo, ST52, 45# steel tubes or bars for choice
2.Do the pre-treatment including pickling, phosphating and saponification, and then cold-draw the seamless steel tubes.
3.Put the steel tubes into the tempering furnace to do the stress relief annealing in convenience of the subsequent the processing.
4.Multi-roll straightening machine, with 10 straightening points, achieves the automatic rolling straight improving the efficiency greatly
5.Heat treatment to obtain work pieces with different properties by changing their internal microstructure or surface chemical composition.
6.Cylindrical degree can be controlled within 0.03mm and the surface roughness is up to 0.4 by honing with range:φ40mm-φ450mm and longest length: 12000mm
7.Machining processes to obtain high precision parts with complex shapes strictly according to the detailed drawings.
8.Electroplating production process fulfills the functional and ornamental requirements for coating work pieces of different dimensions according to specific application requirements.
9.Cleaning all the parts by automatic cleaning machine in the special solution and under special temperature control effectively.
10.All the parts are assembled into complete cylinders according to the strict assembly instructions by skillful workers in dust-free workshop.
11.Do proof pressure and performance tests to check whether the cylinders can operate smoothly and stably under the specified pressure with no leakage and deformation.
12.Do the painting including high quality primer and topcoat to obtain beautiful appearance and protect the cylinders against the anticorrosion.
13.Wooden pallet or boxes packing with plastic films wrapped on the surface, suitable for long-time sea transport.
>All specification is designed by professional engineer.
>All material is high quality-Seal kits were purchased from USA, Japan, UK and Sweden.
>All material is processed by skilled workers and advanced CNC lathe
>All cylinders are 100% tested before package to ensure every cylinder is qualified for its purpose
>Package is air cushion film for each cylinder and steel case for all cylinders to ensure goods can arrive at customer safely
>14 months warranty and long time track service is offered to solve any problems you meet after sale.
Wantong Hydraulic warrants all cylinders to be free from any defects in material or workmanship under normal use and service for a period of 14 months
This warranty does not cover & WANTONG shall have no responsibility for:
1.Troubleshooting, diagnostic, removal, or reinstallation labor charges;
3.Claims for loss of time, inconvenience, loss of use, profits or other consequential damages
4.Conditions from, alteration, accident, misuse, neglect, fire, theft, loss, intentional damage, direct,indirect, consequential, incidental, weather related, or any other type of damage resulting fromthe use of the product;
5.Corrosion unless the material is found to be out of specification;
6.Failure due to contamination introduced to the cylinder;
7.Paint unless out of specification;
Hydraulic cylinder problems occur at warranty period:
(1) New cylinder replace;
(2) price discount in the next order;
(3) the "repair fee" pay: repair fee required to within a reasonable range: the cost of wantong repair problem hydraulic cylinder < repair fee < the cost of production of a new hydraulic cylinder;
(4) for strategic customers, one to one special treatment.
"Pursue zero defect of our products, and realize zero customers' complains"
Founded in 1995, with registration capital of 60 million RMB, Shandong Wantong Hydraulic Co., Ltd is specialized in hydraulic products design,R&D and manufacturing.
We mainly produce Hydraulic Cylinder including Vehicle Hydraulic Cylinder, Coal Mining Hydraulic Cylinder, Engineering Hydraulic Cylinder ,Oil field cylinder and Ocean Engineering Hydraulic Cylinder.Also we can design and manufacture various special purpose hydraulic cylinders such as agriculture hydraulic cylinder,industry hydraulic cylinder, 6 DOF platform, machine tools, etc.
We have more than 120 kinds of hydraulic cylinder , our annual capacity is 200 thousand sets of cylinders which makes our company an important production base for hydraulic cylinders.
Our company covers an area of 180 thousand square meters (193 thousand square feet),and has more than 500 employees.We have solid and advanced production equipments including cold drawing line, heat treatment line, surface treatment line, testing machines and various CNC machines, totally 700 sets of machines.
All production steps are finished in same factory which guarantees good quality and short lead time. All the products have passed validation of ISO/TS16949, CCRI, CCS, and DNV AND ABS,API,etc.
>Professional manufacturer& supplier of Hydraulic Cylinders for more than 22 years;
>Hydraulic Cylinders Certification ISO9001:2008, SGS, TS16949, RoHS, CNAS Certification;
>Experience in export North America, Australia, Asia, Middle East, Africa;
>Hydraulic Cylinders can be Make according to client's requirements;
>The Hydraulic Cylinders can be used for Dump Truck, Tipper Truck, Trailer, Agricultural Machinery, Engineering Machinery, Garbage Truck, Landing Platform etc;
>We are the supplier of Sinotruk, CNHTC, CIMC, Wuzheng, Beiben Truck, Baic Group, FOTON, HOWO, JAC, Sichuan Hyundai, Dayun, Shanxi Automobile, most of famous truck manufacturing and refitting company use our telescopic cylinder as first choice
Q1: Are you a manufacture or a trade company?
A:Manufacture, we are the leader manufacturer of hydraulic industry in China with 22 years' experience and technologyaccumulation.With strong technical team we could solve any annoyance of you.
Q2: Do you have quality control system?
A:Yes, The quality management system introduced is: ISO/TS 16949:2009-certifiedby NQA and IATF cert.
Q3: How can i get a booklet and buy a cylinder from you?
A: Very easy! Just leave me a message or email or call me directly, let me know you are interesting in our products.I will talk with you for the details soon!
Q4: Can you tell me the price for the cylinder?
1. Please advice the drawing with technical requirement.
2. Please advice the model No. after you check our booklet.
3. Please advice the tipping capacity, number of stages, closed length, mounting type and size.
4. Please also help advice the quantities, this is very important.
Q5: Do your products come with a warranty?
A: Yes, we have 14 months warranty. In this year, if the quality problem we will free repair for you.
Q6: Hydraulic cylinder internal leakage?
A: 3 main reasons causing internal leakage: Overload, polishing bad controlled, cheap seal kits. As is known to all, vehicles in China are often overloaded, our products all designed to bear the overload power. Advanced equipment could assure the polish processing. And we use the imported/TOP brand seals to meet customers' requirement.
Q7: What about the quality feedback of your products?
A: We have never received even once quality complaint for many years of international business.
Q8: Can you help me to install or recommend what kind of hydrauliccylinder or power pack should I use for specific machine?
A: Yes, we have 25 experienced engineers who are always ready to help you. If you do not know what kind of hydraulic cylinders should be used in your machine, please just contact us, our engineers will design the exact products match your need.
Q9:What is the delivery time?
A: Within 20 days for samples.
15-30 days for bulk production, which is depend on quality, production process and so on.
Q10: What is your main payment term?
A: T/T, L/C,D/A, D/P either is available.
Q11: What's the MOQ?
A: The MOQ is 1 piece.
